IDEAL TLC 6FRAISRTQ Antenna Connector - 5 - 1 x F Connector Antenna - Nickel Plated
Description
The TLC connector is an indoor, cable specific alternate to the NJX series of products. The TLC connector uses the standard 1/4" x 1/4" cable preparation, that does not require a compression tool to complete the termination process. TLC series connectors feature a sliding post design to capture and secure the cable inside of the connector. After the cable is inserted, tightening the connector to the device completes assembly process, creating a 360° compression point and a permanent connection. IDEAL F/BNC insertion tools (35-046, 35-042, 35-043) can be used (but are not required) when installing the TLC cable assembly to ensure connectors are properly torqued and fully seated to the female barrel. These connectors are designed for applications from 5MHz to 3GHz including CATV and satellite.
Specifications
UNSPSC Code
26121630
Brand
Ideal
Brand Name
Ideal
Connector Details
1 x F Connector Antenna
Connector Plating
Nickel
Connector Type
F Connector Antenna
Country of Origin
China
Features
Corrosion Resistant
Manufacturer Part Number
92-691
Packaged Quantity
5
Product Family
TLC
Product Material
Brass
Product Series
TLC
Product Type
Antenna Connector
