Tripp Lite by Eaton PDU 3.7kW Single-Phase Switched PDU - LX Interface 208/230V Outlets (20 C13 & 4 C19) C20/L6-20P 0U TAA - Switched - NEMA L6-20P, IEC 60320 C20 - 4 x IEC 60320 C19, 20 x IEC 60320 C13 - 230 V AC - 0U - Vertical - Rack Mount - TAA Compli
- Provide circuit protection and easy configuration for trouble-free access
- Remotely control individual outlets for rebooting of locked equipment with switched PDUs
Description
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP and NTP.
A digital ammeter allows you to monitor each bank's load in real time to ensure it remains well below maximum capacity with no danger of overload. The vertical PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
Specifications
UNSPSC Code
39121017
Brand
Eaton
Brand Name
Eaton
Category
PDUs
Country of Origin
Taiwan
Depth
2.6"
Environmental Compliance
Restriction of Hazardous Substances (RoHS)
Environmentally Friendly
Yes
Height
70"
Input Current
20 A
Input Voltage
230 V AC
Input Voltage Range
200 V AC - 240 V AC
Limited Warranty
2 Year
Management
Protocols:
- HTTP
- HTTPS
- SMTP
- SNMPv1
- SNMPv2
- SNMPv3
- telnet
- SSH
- FTP
- DHCP
- NTP
Manufacturer
Eaton Corporation
Manufacturer Part Number
PDUMV20HVNETLX
Manufacturer Website Address
http://www.eaton.com/EatonCom/Markets/NorthAmerica
Mount Type
Rack-mountable
Mounting Orientation
Vertical
Output Voltage
230 V AC
PDU Type
Switched
Phase
Single Phase
Plug/Connector Type
NEMA L6-20P
Power Rating (Watt)
3800 W
Product Model
PDUMV20HVNETLX
Product Name
PDUMV20HVNETLX 24-Outlet PDU
Product Type
PDU
Rack Height
0U
Receptacle Detail
4 x IEC 60320 C19
Receptacle Type
IEC 60320 C19
TAA Compliant
Yes
Weight (approximate)
8.50 lb
Width
2.2"
